Dimensions
- Machine length: 2915 mm
- Wheelbase: 2000 mm
- Machine height: 2840 mm
- Machine height (folder rops): 2150 mm
- Drum width: 1300 mm
- Tire-axle width: 1275 mm
- Machine length: 3000 mm
- Ground clearance: 330 mm
- Side clearance: 605 mm
- Drum diameter: 850 mm
- Drum shell thickness: 18 mm
- Machine width (total): 1385 mm
Weight & operating characteristics
- Operating weight: 4055 kg
- Operating weight max.: 4355 kg
- Stat. lin. load: 16.5 kg/cm
- Turning radius inside: 2830 mm
- Steering / oscillating angle: 35/9 ±°
Engine
| ARX 40-2C light tandem vibratory roller (EU Stage V / U.S. EPA Tier 4 Final) | ARX 40-2C light tandem vibratory roller (EU Stage IIIA / U.S. EPA Tier 4 Interim) | |
|---|---|---|
| Engine Type: | Kubota D1803-CR-T | Kubota V2403-M |
| Emission class: | EU Stage V / U.S. EPA Tier 4 Final | EU Stage IIIA / U.S. EPA Tier 4i |
| Power output ISO 3046: | 32.8 kW (44 HP) | 34.1 kW (45.7 HP) |
| Cylinder / ltr.: | 3 cyl / 1826 cm³ | 4 cyl / 2434 cm³ |
| Nominal speed: | 2400 rpm | 2400 rpm |
| Travel speed: | 10 km/h | 10 km/h |
| Gradeability with / without vibr.: | 30 % / 40 % | 30 % / 40 % |
Compaction Forces
- Amplitude I: 0.4 mm
- Amplitude II: 0.6 mm
- Frequency I: 41 Hz
- Frequency II: 55 Hz
- Centrifugal force I: 42.4 kN
- Centrifugal force II: 53.8 kN
- Centrifugal force III: 55 kN
Miscellaneous Forces
- Battery / capacity: 12/77 V/Ah
- Water tank: 340 l
- Anti-adhesive tank: 18 l
- Hydraulic tank: 53.5 l
- Diesel fuel tank: 57 l
- Wheel load: 481 kg
- Number of wheels: 4
- Tire size: 10,5/80-16
